VLT® 7000 Booster
■ Technical data, mains supply 3 x 380-460V
According to international requirements VLT type 7002 7003 7004 7005 7006 7008 7011
Output current
I
VLT,N
[A] (380-440
V)
3.0 4.1 5.6 7.2 10.0 13.0 16.0
I
VLT, MAX
(60 s) [A]
(380-440 V)
3.3 4.5 6.2 7.9 11.0 14.3 17.6
I
VLT, N
[A] (441-460
V)
3.0 3.4 4.8 6.3 8.2 11.0 14.0
I
VLT, MAX
(60 s) [A]
(441-460 V)
3.3 3.7 5.3 6.9 9.0 12.1 15.4
Output power S
VLT,N
[kVA] (400 V) 2.2 2.9 4.0 5.2 7.2 9.3 11.5
S
VLT,N
[kVA] (460 V) 2.4 2.7 3.8 5.0 6.5 8.8 11.2
Typical s haft
output
P
VLT,N
[kW] 1.1 1.5 2.2 3.0 4.0 5.5 7.5
Typical s haft
output
P
VLT,N
[HP] 1.5 2 3 - 5 7.5 10
Max. cable
cross-section to
motor
[mm
2
]/[AWG]
2) 4)
4/10 4/10 4/10 4/10 4/10 4/10 4/10
Max. input
current
I
L,N
[A] (380 V) 2.8 3.8 5.3 7.0 9.1 12.2 15.0
(RMS) I
L,N
[A] (460 V) 2.5 3.4 4.8 6.0 8.3 10.6 14.0
Max. cable
cross-section
power
[mm
2
]/[AWG]
2) 4)
4/10 4/10 4/10 4/10 4/10 4/10 4/10
Max. pre-fuses [-]/UL
1)
[A] 16/6 16/10 16/10 16/15 25/20 25/25 35/30
Mains contactor [Danfoss type] CI 6 CI 6 CI 6 CI 6 CI 6 CI 6 CI 6
Efficiency
3)
0.96 0.96 0.96 0.96 0.96 0.96 0.96
Weight IP 20 [kg] 8 8 8.5 8.5 10.5 10.5 10.5
Power loss at
max. load. [W]
Total 67 92 110 139 198 250 295
Enclosure VLT type IP 20
1. Fortypeoffuse,seesectionFuses.
2. American Wire Gauge.
3. Measured using 30 m screened motor cables at rated load and rated frequency.
4. Max. cable cross section is the maximum possible cable cross section that can be fitted on the terminals.
Always comply with national and local regulations on min. cable cross-sectio
n.
MG.70.A1.02 - VLT is a registered Danfoss trademark
18
