VLT® 7000 Booster
Installation
■ Technical data, mains supply 3x380-460V
According to international requirements VLT type 7016 7022 7027 7032 7042
Output current I
VLT,N
[A] (380-440 V) 24.0 32.0 37.5 44.0 61.0
I
VLT, MAX
(60 s) [A]
(380-440 V)
26.4 35.2 41.3 48.4 67.1
I
VLT,N
[A] (441-460 V) 21.0 27.0 34.0 40.0 52.0
I
VLT, MAX
(60 s) [A]
(441-460 V)
23.1 29.7 37.4 44.0 57.2
Output power S
VLT,N
[kVA] (400 V) 17.3 23.0 27.0 31.6 43.8
S
VLT,N
[kVA] (460 V) 16.7 21.5 27.1 31.9 41.4
Typical shaft output P
VLT,N
[kW] 11 15 18.5 22 30
Typical shaft output P
VLT,N
[HP] 15 20 25 30 40
Max. cable cross-section to
motor and DC-bus, IP 20
[mm
2
]/[AWG]
2) 4)
16/6 16/6 16/6 35/2 35/2
Min. cable cross-section to
motor and DC-bus
[mm
2
]/[AWG]
2) 4)
10/8 10/8 10/8 10/8 10/8
Max. input current I
L,N
[A] (380 V) 24.0 32.0 37.5 44.0 60.0
(RMS) I
L,N
[A] (460 V) 21.0 27.6 34.0 41.0 53.0
Max. cable cross-section
power, IP 20
[mm
2
]/[AWG]
2) 4)
16/6 16/6 16/6 35/2 35/2
Max. pre-fuses [-]/UL
1)
[A] 63/40 63/40 63/50 63/60 80/80
Mains contactor [Danfoss type] CI 9 CI 16 CI 16 CI 32 CI 32
Efficiency at rated frequency 0.96 0.96 0.96 0.96 0.96
Weight IP 20 [kg] 21 21 22 27 28
Power loss at max. load. [W] 419 559 655 768 1065
Enclosure IP 20
1. Fortypeoffuse,seesectionFuses.
2. American Wire Gauge.
3. Measured using 30 m screened motor cables at rated load and rated frequency.
4. Min. cable cross-section is the smallest cable cross-section allowed to be fitted on the terminals. Max. cable cross section is the
maximum possible cable cross section that can be fitted on the terminals.
Always comply with national and local regulations on min. cable cross-sectio
n.
MG.70.A1.02 - VLT is a registered Danfoss trademark
19
