VLT® 7000 Booster
Installation
■ Mechanical dimensions
All the below listed measurements are in mm.
VLT type A B C a b aa/bb Type
Bookstyle IP 20 380 - 460 V
7002 - 7005 395 90 260 384 70 100 A
7006 - 7011 395 130 260 384 70 100 A
IP 20 380 - 460 V
7002 - 7005 395 220 160 384 200 100 C
7006 - 7011 395 220 200 384 200 100 C
7016 - 7027 560 242 260 540 200 200 D
7032 - 7042 700 242 260 680 200 200 D
7052 - 7072 800 308 296 780 270 200 D
MG.70.A1.02 - VLT is a registered Danfoss trademark
21
