VLT® 7000 Booster
Max. terminal load (AC) on 1-3, 1-2 power card ................................................................... 240 V AC, 2 A, 60 VA
Max. terminal load DC-1 (IEC 947) on 1-3, 1-2, power card and relay card ....................................... 50 V DC, 2 A
Min. terminal load on 1-3, 1-2, power card ...................................................... 24 V DC, 10 mA, 24 V AC, 100 mA
Cable lengths and cross-sections:
Max. motor cable length, screened cable ..................................................................................................... 150 m
Max. motor cable length, unscreened cable ................................................................................................. 300 m
Max. motor cable length, screened cable VLT 7011 380-460 V .................................................................... 100 m
Max. DC-bus cable length, screened cable ........................................... 25 m from frequency converter to DC bar.
Max. cable cross-section to motor, see nex t section
Max. cross-section for control cables ....................................................................................... 1.5 mm
2
/16 AWG
Max. cross-section for serial communication ............................................................................ 1.5 mm
2
/16 AWG
Control characteristics:
Frequency range .................................................................................................................................. 0 - 1000 Hz
Resolution on output frequency ............................................................................................................. ±0.003 Hz
System response time ............................................................................................................................... 3 msec.
Speed, control range (open loop) ..................................................................................... 1:100 of synchro. speed
Speed, accuracy (open loop) ............................................................................ < 1500 rpm: max. error ± 7.5 rpm
>1500 rpm: max. error of 0.5% of actual speed
Process, accuracy (closed loop) ....................................................................... < 1500 rpm: max. error ± 1.5 rpm
>1500 rpm: max. error of 0.1% of actual speed
All control characteristics are based on a 4-pole asynchronous motor
Accuracy of display readout (parameters 009-012, Display readout):
Motor current [5] 0-140% load ............................................................... Max. error: ±2.0% of rated output current
Power kW [6], Power HP [7], 0-90% load .................................................. Max. error: ±5% of rated output power
Externals:
Enclosure ....................................................................................................................................................... IP 20
Vibration test .................................. 0.7 g RMS 18-1000 Hz random. 3 directions for 2 hours (IEC 68-2-34/35/36)
Max. relative humidity ............................................................ 93 % + 2 %, -3 % (IEC 68-2-3) for storage/transport
Max. relative humidity ............................................... 95 % non condensing (IEC 721-3-3; class 3K3) for operation
Aggressive environment (IEC 721-3-3) ........................................................................................ Coated class 3C3
Ambient temperature, 7002-7011 380-460 V, Bookstyle, IP 20 ............. Max. 45°C (24-hour average max. 40°C)
Ambient temperature, 7016-7072 380-460 V, IP 20 ............................... Max. 40°C (24-hour average max. 35°C)
Min. ambient temperature in full operation ........................................................................................................ 0°C
Min. ambient temperature at reduced performance ..................................................................................... -10°C
Temperature during storage/transport ............................................................................................. -25 - +65/70°C
Max. altitude above sea level ...................................................................................................................... 1000 m
EMC standards applied, Emission ......................................... EN 61000-6-3/4, EN 61800-3, EN 55011, EN 55014
EMC standards applied, Immunity ................................................................................................ EN 50082-2, EN
61000-4-2, IEC 1000-4-3, EN 61000-4-4, EN 61000-4-5, ENV 50204, EN 61000-4-6, VDE 0160/1990.12
Relay outputs on the Cascade Card:
Relay 71-78: ......................................................................................................... Terminal 8 A-D and 71-78 make
Max. cross section: .................................................................................................................................. 1,5 mm
2
Torque: ............................................................................................................................................. 0,22-0,25 Nm
VLT 7000 Boosterprotection
• Electronic motor thermal protection against overload.
• Temperature monitoring of heat-sink ensures that the frequency converter cuts out if the temperature reaches
90°C. An overtemperature can only be reset when the temperature of the heat-sink has fallen below 60°C.
• The frequency converter is protected against short-circuiting on motor termi
nals U, V, W.
MG.70.A1.02 - VLT is a registered Danfoss trademark
16
