VLT® 7000 Booster
Programming
Feedback [unit] (FEEDBACK [UNITS])
[15]
Motor voltage [V] (MOTOR VOLTAGE [V])
[16]
DC link voltage [V] (DC VOLTAGE [V])
[17]
Thermal load, motor [%]
(THERM.MOTOR LOAD [%])
[18]
Thermal load, VLT [%]
(THERM.DRIVE LOAD [%])
[19]
Digital input [Binary code]
(DIGITAL INPUT [BIN])
[20]
Analogue input 53 [V] (ANALOG INPUT 53 [V])
[21]
Analogue input 54 [V] (ANALOG INPUT 54 [V])
[22]
Analogue input 60 [mA]
(ANALOG INPUT 60 [MA])
[23]
Relay status [binary code] (RELAY STATUS)
[24]
Pulse reference [Hz] (PULSE REFERENCE [HZ])
[25]
External reference [%] (EXT. REFERENCE [%])
[26]
Heat sink temp. [°C] (HEATSINK TEMP [°C])
[27]
Communication option card warning
(COMM OPT WARN [HEX])
[28]
LCP display text (FREE PROG.ARRAY)
[29]
Status word (STATUS WORD [HEX])
[30]
Control word (CONTROL WORD [HEX])
[31]
Alarm word (ALARM WORD [HEX])
[32]
Function:
This parameter allows a choiceofthedatavalueto
be shown in the display, line 2, when the frequency
converter is turned on. The data values will also be
included in the display mode scroll-list. Parameters
008-010 Small display readout allow a choice of
another three data values, shown in line 1.
See the description of the control unit.
Description of choice:
No readout can only be selected in parameters
008-010 Small display readout.
Resulting reference [%] gives a percentage for
the resulting reference in the range from Minimum
reference,Ref
MIN
to Maximum reference, Ref
MAX
. See also reference handling.
Reference [unit] gives the resulting reference in Hz
in Open loop.InClosed loop, the reference unit is
selected in parameter 415 Process units.
Frequency [Hz] gives the output frequency
from the frequency converter.
% of maximum output frequency [%] is the present
output frequency as a percentage value of parameter
202 Output frequency high limit, f
MAX
.
Motor current [A] states the phase current of the
motor measured as effective value.
Power [kW] states the actual power consumed
by the motor in kW.
Power [HP] states the actual power consumed
by the motor in HP.
Output energy [kWh] states the energy consumed
by the motor since the latest reset was made in
pa-rameter 618 Reset of kWh counter.
Hours run [Hours] states the number of hours
that the motor has run since the latest reset in
parameter 619 Reset of hours-run counter.
User -defined readout [-] is a user-defined value,
calculated on the basis of the present output frequency
and unit, as well as the scaling in parameter 005
Max. value of user-defined readou t. Select unit in
parameter 006 Unit for user-defined readout.
Setpoint 1 [unit] is the programmed setpoint
value in parameter 418 Setpoint 1.Theunit
is decided in parameter 415 Process units .
See also Feedback handling.
Setpoint 2 [unit] is the programmed setpoint value
in parameter 419 Setpoint 2. The unit is decided
in parameter 415 Process units.
Feedback 1 [unit] gives the signal value of the resulting
feedback 1 (Term. 53). The unit is decided in parameter
415 Process units. See also Feedback handling .
Feedback 2 [unit] gives the signal value of the
resulting feedback 2 (Term. 53). The unit is decided
in parameter 415 Process units.
Feedback [unit] gives the resulting signal value
using the unit/scaling selected in parameter 413
Minimum feedback,FB
MIN
, 414 Maximum feedback,
FB
MAX
and 415 Process units .
Motor voltage [V] states the voltage supplied
to the motor.
DC link voltage [V] states the intermediate circuit
voltage in the frequency converter.
Thermal load, motor [%] states the calculated/
estimated thermal load on the motor. 100%
is the cut-out limit. See also parameter 117
Motor thermal protection.
Thermal load, VLT [%] states the calculated/
estimated thermal load on the frequency converter.
100% is the cut-out limit.
Digital input [Binary code] states the signal status
from the 8 digital inputs (16, 17, 18, 19, 27, 29, 32
and 33). Terminal 16 corresponds to th
ebitatthefar
left. ‘0’ =nosignal,‘1’ = connected signal.
Analogue input 53 [V] states the voltage
value on terminal 53.
Analogue input 54 [V] states the voltage
value on terminal 54.
Analogue input 60 [mA] states the vol
tage
value on terminal 60.
Relaystatus[binarycode]indicates the status of
each relay. The left (most significa
nt) bit indicates
relay 1 followed by 2 and 6 through 9. A "1" indicates
the relay is active, a "0" indicates inactive. Paramater
007 uses an 8-bit word with th
e last two positions
✭
= factory setting. () = display text [] = value for use in communication via serial communication port
MG.70.A1.02 - VLT is a registered Danfoss trademark
51
