Danfoss VLT AQUA Drive Series User Manual

Illustration 5.34: Inverter Cabinet, frame size F2 and F4
1) External Temperature Monitoring 6) Motor
2) AUX Relay U V W
01 02 03 96 97 98
04 05 06 T1 T2 T3
3) NAMUR 7) NAMUR Fuse. See fuse tables for part numbers
4) AUX Fan 8) Fan Fuses. See fuse tables for part numbers
100 101 102 103 9) SMPS Fuses. See fuse tables for part numbers
L1 L2 L1 L2
5) Brake
-R +R
81 82
5 How to Install VLT
®
AQUA Drive Design Guide
142 MG.20.N5.02 - VLT
®
is a registered Danfoss trademark
5
