Danfoss VLT AQUA Drive Series User Manual

FC 202, P7K5T4
Cable
length [m]
Mains
voltage [V]
Rise time
[μsec]
Vpeak
[kV]
dU/dt
[kV/μsec]
5 500 0.04755 0.739 8.035
50 500 0.207 4.548
150 500 0.6742 1.030 2.828
FC 202, P11KT4
Cable
length [m]
Mains
voltage [V]
Rise time
[μsec]
Vpeak
[kV]
dU/dt
[kV/μsec]
15 480 0.192 1.300 5.416
100 480 0.612 1.300 1.699
150 480 0.512 1.290 2.015
FC 202, P15KT4
Cable
length [m]
Mains
voltage [V]
Rise time
[μsec]
Vpeak
[kV]
dU/dt
[kV/μsec]
36 480 0.396 1.210 2.444
100 480 0.844 1.230 1.165
150 480 0.696 1.160 1.333
FC 202, P18KT4
Cable
length [m]
Mains
voltage [V]
Rise time
[μsec]
Vpeak
[kV]
dU/dt
[kV/μsec]
36 480 0.396 1.210 2.444
100 480 0.844 1.230 1.165
150 480 0.696 1.160 1.333
FC 202, P22KT4
Cable
length [m]
Mains
voltage [V]
Rise time
[μsec]
Vpeak
[kV]
dU/dt
[kV/μsec]
36 480 0.312 2.846
100 480 0.556 1.250 1.798
150 480 0.608 1.230 1.618
FC 202, P30KT4
Cable
length [m]
Mains
voltage [V]
Rise time
[μsec]
Vpeak
[kV]
dU/dt
[kV/μsec]
15 480 0.288 3.083
100 480 0.492 1.230 2.000
150 480 0.468 1.190 2.034
FC 202, P37KT4
Cable
length [m]
Mains
voltage
Rise time
[μsec]
Vpeak
[kV]
dU/dt
[kV/μsec]
5 480 0.368 1.270 2.853
50 480 0.536 1.260 1.978
100 480 0.680 1.240 1.426
150 480 0.712 1.200 1.334
VLT
®
AQUA Drive Design Guide 3 VLT AQUA Selection
MG.20.N5.02 - VLT
®
is a registered Danfoss trademark 57
