Danfoss VLT AQUA Drive - How to Install

4.2. How to install
4.2.1. Checklist
Please use the following table to follow mounting instructions
Enclosure:
A2
(IP 20/
21)
A3
(IP 20/
21)
A5
(IP 55/
66)
B1 /B3
(IP
20/ 21/
55/66)
B2 /B4
(IP20/ 21/
55/66)
C1/C3
(IP20/21/ 55/66)
C2/C4
(IP20/21/
55/66)
Unit size:
200-240 V
0.25-3.0
kW
3.7
kW
0.25-3.7
kW
5.5-11 kW
15
kW
18.5-30
kW
37-45
kW
380-480 V
0.37-4.0
kW
5.5-7.5 kW
0.37-7.5
kW
11-18.5
kW
22-30
kW
37-55
kW
75-90
kW
525-600 V 0.75-4.0 kW 5.5-7.5 kW 0.75-7.5 kW
11-18.5
kW
22-37
kW
45-55 kW
75-90
kW
Table 4.2: Mounting table.
The frequency converter can be mounted side by side for all IP rating units and requires 100 mm free space above and below for cooling. With regard
to ambient temperature ratings, please see Special Conditions.
