6-25 Terminal 54 high ref./feedb. value
Range: Function:
100.000 Unit
*
[Par. 6-24 to
1000000.000]
Enter the analog input scaling value that corresponds to the high voltage/high current value set in par. 6-21 and
par. 6-23.
6-50 Terminal 42 Output
Option: Function:
Select the function of Terminal 42 as an analog current output.
[0] No operation
[100]
*
Output frequency : 0 - 100 Hz
[101] Reference : Minimum reference - Maximum reference
[102] Feedback : -200% to +200% of par. 2-14
[103] Motor current : 0 - Inverter Max. Current (par. 16-37)
[104] Torque rel to lim : 0 - Torque limit (par. 4-16)
[105] Torque rel to rated : 0 - Motor rated torque
[106] Power : 0 - Motor rated power
[107] Speed : 0 - Speed High Limit (par. 4-13 and par. 4-14)
[113] Ext. closed loop 1 : 0 - 100%
[114] Ext. closed loop 2 : 0 - 100%
[115] Ext. closed loop 3 : 0 - 100%
[130] Output freq. 4-20mA :0 - 100 Hz
[131] Reference 4-20mA :Minimum Reference - Maximum Reference
[132] Feedback 4-20mA :-200% to +200% of par. 2-14
[133] Motor cur. 4-20 mA :0 - Inverter Max. Current (par. 16-37)
[134] Torque % lim. 4-20 mA :0 - Torque limit (par. 4-16)
[135] Torque % nom 4-20
mA
:0 - Motor rated torque
[136] Power 4-20 mA :0 - Motor rated power
[137] Speed 4-20 mA :0 - Speed High Limit (par. 4-13 and par. 4-14)
[139] Bus ctrl. 0-20 mA :0 - 100%
[140] Bus ctrl. 4-20 mA : 0 - 100%
[141] Bus ctrl. 0-20 mA, time-
out
: 0 - 100%
[142] Bus ctrl. 4-20 mA, time-
out
: 0 - 100%
[143] Ext. Closed Loop 1,
4-20 mA
: 0 - 100%
[144] Ext. Closed Loop 2,
4-20 mA
: 0 - 100%
[145] Ext. Closed Loop 3,
4-20 mA
: 0 - 100%
NB!
Values for setting the Minimum Reference is found in par. 3-02
Open Loop
and par. 20-13
Closed Loop
- values for Maximum Reference is found in
par. 3-03
Open Loop
and par. 20-14
Closed Loop
.
