NB!
The frequency converter has no back up of the clock function and the set date/time will reset
to default (2000-01-01 00:00) after a power down unless a Real Time Clock module with back
up is installed. In par. 0-79,
Clock Fault
, it is possible to program for a Warning in case clock
has not been set properly, e.g. after a power down.
23-03 OFF Action
Option: Function:
Select the action during OFF Time. See par. 13.52
SL Controller Action
for descriptions of the options.
Array [10]
[0]
*
DISABLED
[1] No action
[2] Select setup 1
[3] Select setup 2
[4] Select setup 3
[5] Select setup 4
[10] Select preset ref. 0
[11] Select preset ref. 1
[12] Select preset ref. 2
[13] Select preset ref. 3
[14] Select preset ref. 4
[15] Select preset ref. 5
[16] Select preset ref. 6
[17] Select preset ref. 7
[18] Select ramp 1
[19] Select ramp 2
[22] Run
[23] Run reverse
[24] Stop
[26] DC brake
[27] Coast
[28] Freeze output
[29] Start timer 0
[30] Start timer 1
[31] Start timer 2
[32] Set dig. out. A low
[33] Set dig. out. B low
[34] Set dig. out. C low
[35] Set dig. out. D low
[36] Set dig. out. E low
[37] Set dig. out. F low
[38] Set dig. out. A high
[39] Set dig. out. B high
[40] Set dig. out. C high
[41] Set dig. out. D high
[42] Set dig. out. E high
8. How to programme the frequency converter
VLT
®
AQUA Drive
Operating Instructions
96
MG.20.M4.02 - VLT
®
is a registered Danfoss trademark
8
