8.2.12. Water Application Functions, 29-**
The group contains parameters used for monitoring water / wastewater applications.
29-00 Pipe Fill Enable
Option: Function:
[0] *
Disabled
[1] Enabled Select Enabled to fill pipes with a user specified rate.
29-01 Pipe Fill Speed [RPM]
Range: Function:
Speed Low Limit * [Speed Low Limit
- Speed High Limit]
Set the filling speed for filling horizontal pipe systems. The speed can be selected in Hz or RPM depending on
the choice in P4-11/P4-13 (RPM) or P4-12/P4-14 (Hz).
29-02 Pipe Fill Speed [Hz]
Range: Function:
Motor Speed Low Limit * [Speed Low
Limit - Speed High Limit]
Set the filling speed for filling horizontal pipe systems. The speed can be selected in Hz or RPM depending on
the choice in P4-11/P4-13 (RPM) or P4-12/P4-14 (Hz).
29-03 Pipe Fill Time
Range: Function:
0 s * [0 - 3600 s]
Set the specified time for Pipe Fill of horizontal pipe systems.
29-04 Pipe Fill Rate
Range: Function:
0.001 units/s * [0.001 –
999999.999]
Specifies the filling rate units/second using the PI controller. Fill Rate units are Feedback Units/second. This
function is for filling up vertical pipe systems.
29-05 Filled Setpoint
Range: Function:
0 s * [0 – 999999,999]
Specifies the Filled Setpoint at which the Pipe Fill Function will be disabled and PID controller will take control.
This can be used both for horizontal and vertical pipe systems.
