[65] Reset Counter B Input for reset of counter B.
[70] Mech. Brake Feedback Brake feedback for hoisting applications: Set par 1-01 to [3]
flux w/ motor feedback
; set par 1-72
to [6]
Hoist mech brake Ref.
[71] Mech. Brake Feedback inv. Inverted brake feedback for hoisting applications
[72] PID error inverse When enabled, it inverts the resulting error from the process PID controller. Available only if "Con-
figuration Mode" is set to "Surface Winder," "Extended PID Speed OL" or "Extended PID Speed CL."
[73] PID reset I-part When enabled, resets the I-part of the process PID controller. Equivalent to par. 7-40. Available
only if "Configuration Mode" is set to "Surface Winder," "Extended PID Speed OL" or "Extended PID
Speed CL."
[74] PID enable When enabled, enables the extended process PID controller. Equivalent to par. 7-50. Available only
if "Configuration Mode" is set "Extended PID Speed OL" or "Extended PID Speed CL."
[80] PTC Card 1 All digital inputs can be set to PTC card 1 [80]. However, only one digital input must be set to this
choice.
4.3.3 5-3* Digital Outputs
Parameters for configuring the output functions for the output terminals. The 2 solid-state digital outputs are common for terminals 27 and 29. Set the
I/O function for terminal 27 in par. 5-01
Terminal 27 Mode
, and set the I/O function for terminal 29 in par. 5-02
Terminal 29 Mode
. These parameters
cannot be adjusted while the motor is running.
[0] No operation
Default for all digital outputs and relay outputs
[1] Control ready The control card is ready. For example, Feedback from a drive where the control is supplied by an
external 24 V (MCB107) and the main power to drive is not detected.
[2] Drive ready The adjustable frequency drive is ready for operation and applies a supply signal on the control
board.
[3] Drive ready / remote control The adjustable frequency drive is ready for operation and is in Auto On mode.
[4] Enable / no warning Ready for operation. No start or stop command is been given (start/disable). No warnings are active.
[5] VLT running Motor is running and shaft torque is present.
[6] Running / no warning Output speed is higher than the speed set in par. 1-81
Min Speed for Function at Stop [RPM]
. The
motor is running and there are no warnings.
[7] Run in range/no warning Motor is running within the programmed current and speed ranges set in par. 4-50
Warning Current
Low
to par. 4-53
Warning Speed High
. There are no warnings.
[8] Run on reference / no warning Motor runs at reference speed. No warnings.
[9] Alarm An alarm activates the output. There are no warnings.
[10] Alarm or warning An alarm or a warning activates the output.
[11] At torque limit The torque limit set in par. 4-16
Torque Limit Motor Mode
or par. 4-17 has been exceeded.
[12] Out of current range The motor current is outside the range set in par. 4-18
Current Limit
.
[13] Below current, low Motor current is lower than set in par. 4-50
Warning Current Low
.
[14] Above current, high Motor current is higher than set in par. 4-51
Warning Current High
.
[15] Out of speed range Output frequency is outside the frequency ranges set in par. 4-52
Warning Speed Low
and
par. 4-53
Warning Speed High
.
[16] Below speed, low Output speed is lower than the setting in par. 4-52
Warning Speed Low
.
[17] Above speed, high Output speed is higher than the setting in par. 4-53
Warning Speed High
.
[18] Out of feedback range Feedback is outside the range set in par. 4-56
Warning Feedback Low
and par. 4-57
Warning Feed-
back High
.
[19] Below feedback low Feedback is below the limit set in par. 4-56
Warning Feedback Low
.
4 How to Program
VLT
®
AutomationDrive FC 300 Instruction
Manual
4-22
MG.33.AG.22 - VLT
®
is a registered Danfoss trademark
4
