Danfoss VLT AutomationDrive FC 301 User Manual

FC Type
Max. fuse size
1)
Min. rated Voltage Type
K37-1K5 10A 380-500 V type gG
2K2-4K0 20A 380-500 V type gG
5K5-7K5 32A 380-500 V type gG
11K-18K 63A 380-500 V type gG
22K 80A 380-500 V type gG
30K 100A 380-500 V type gG
37K 125A 380-500 V type gG
45K 160A 380-500 V type aR
55K-75K 250A 380-500 V type aR
UL Compliance
200-240 V
FC Type Bussmann Bussmann Bussmann Bussmann Bussmann Bussmann
kW Type RK1 Type J Type T Type CC Type CC Type CC
K25-K37 KTN-R05 JKS-05 JJN-06 FNQ-R-5 KTK-R-5 LP-CC-5
K55-1K1 KTN-R10 JKS-10 JJN-10 FNQ-R-10 KTK-R-10 LP-CC-10
1K5 KTN-R15 JKS-15 JJN-15 FNQ-R-15 KTK-R-15 LP-CC-15
2K2 KTN-R20 JKS-20 JJN-20 FNQ-R-20 KTK-R-20 LP-CC-20
3K0 KTN-R25 JKS-25 JJN-25 FNQ-R-25 KTK-R-25 LP-CC-25
3K7 KTN-R30 JKS-30 JJN-30 FNQ-R-30 KTK-R-30 LP-CC-30
5K5 KTN-R50 KS-50 JJN-50 - - -
7K5 KTN-R60 JKS-60 JJN-60 - - -
11K KTN-R80 JKS-80 JJN-80 - - -
15K-18K5 KTN-R125 JKS-150 JJN-125 - - -
FC Type SIBA Littel fuse
Ferraz-
Shawmut
Ferraz-
Shawmut
kW Type RK1 Type RK1 Type CC Type RK1
K25-K37 5017906-005 KLN-R05 ATM-R05 A2K-05R
K55-1K1 5017906-010 KLN-R10 ATM-R10 A2K-10R
1K5 5017906-016 KLN-R15 ATM-R15 A2K-15R
2K2 5017906-020 KLN-R20 ATM-R20 A2K-20R
3K0 5017906-025 KLN-R25 ATM-R25 A2K-25R
3K7 5012406-032 KLN-R30 ATM-R30 A2K-30R
5K5 5014006-050 KLN-R50 - A2K-50R
7K5 5014006-063 KLN-R60 - A2K-60R
11K 5014006-080 KLN-R80 - A2K-80R
15K-18K5 2028220-125 KLN-R125 - A2K-125R
FC Type Bussmann SIBA Littel fuse
Ferraz-
Shawmut
kW Type JFHR2 Type RK1 JFHR2 JFHR2
22K FWX-150 2028220-150 L25S-150 A25X-150
30K FWX-200 2028220-200 L25S-200 A25X-200
37K FWX-250 2028220-250 L25S-250 A25X-250
KTS-fuses from Bussmann may substitute KTN for 240 V frequency converters.
FWH-fuses from Bussmann may substitute FWX for 240 V frequency converters.
KLSR fuses from LITTEL FUSE may substitute KLNR fuses for 240 V frequency converters.
L50S fuses from LITTEL FUSE may substitute L50S fuses for 240 V frequency converters.
A6KR fuses from FERRAZ SHAWMUT may substitute A2KR for 240 V frequency converters.
A50X fuses from FERRAZ SHAWMUT may substitute A25X for 240 V frequency converters.
380-500 V
FC Type Bussmann Bussmann Bussmann Bussmann Bussmann Bussmann
kW Type RK1 Type J Type T Type CC Type CC Type CC
K37-1K1 KTS-R6 JKS-6 JJS-6 FNQ-R-6 KTK-R-6 LP-CC-6
1K5-2K2 KTS-R10 JKS-10 JJS-10 FNQ-R-10 KTK-R-10 LP-CC-10
3K0 KTS-R15 JKS-15 JJS-15 FNQ-R-15 KTK-R-15 LP-CC-15
4K0 KTS-R20 JKS-20 JJS-20 FNQ-R-20 KTK-R-20 LP-CC-20
5K5 KTS-R25 JKS-25 JJS-25 FNQ-R-25 KTK-R-25 LP-CC-25
7K5 KTS-R30 JKS-30 JJS-30 FNQ-R-30 KTK-R-30 LP-CC-30
11K KTS-R40 JKS-40 JJS-40 - - -
15K KTS-R50 JKS-50 JJS-50 - - -
18K KTS-R60 JKS-60 JJS-60 - - -
22K KTS-R80 JKS-80 JJS-80 - - -
30K KTS-R100 JKS-100 JJS-100 - - -
37K KTS-R125 JKS-150 JJS-150 - - -
45K KTS-R150 JKS-150 JJS-150 - - -
