Danfoss VLT AutomationDrive FC 301

FC Type SIBA Littel fuse
Ferraz-
Shawmut
Ferraz-
Shawmut
kW Type RK1 Type RK1 Type CC Type RK1
K37-1K1 5017906-006 KLS-R6 ATM-R6 A6K-6R
1K5-2K2 5017906-010 KLS-R10 ATM-R10 A6K-10R
3K0 5017906-016 KLS-R15 ATM-R15 A6K-15R
4K0 5017906-020 KLS-R20 ATM-R20 A6K-20R
5K5 5017906-025 KLS-R25 ATM-R25 A6K-25R
7K5 5012406-032 KLS-R30 ATM-R30 A6K-30R
11K 5014006-040 KLS-R40 - A6K-40R
15K 5014006-050 KLS-R50 - A6K-50R
18K 5014006-063 KLS-R60 - A6K-60R
22K 2028220-100 KLS-R80 - A6K-80R
30K 2028220-125 KLS-R100 - A6K-100R
37K 2028220-125 KLS-R125 - A6K-125R
45K 2028220-160 KLS-R150 - A6K-150R
FC Type Bussmann Bussmann Bussmann Bussmann
kW JFHR2 Type H Type T JFHR2
55K FWH-200 - - -
75K FWH-250 - - -
FC Type SIBA Littel fuse
Ferraz-
Shawmut
Ferraz-
Shawmut
kW Type RK1 JFHR2 JFHR2 JFHR2
55K 2028220-200 L50S-225 - A50-P225
75K 2028220-250 L50S-250 A50-P250
Ferraz-Shawmut A50QS fuses may be substituted for A50P fuses.
170M fuses shown from Bussmann use the -/80 visual indicator. –TN/80 Type T, -/110 or TN/110 Type T indicator fuses of the same size and
amperage may be substituted.
550 - 600V
FC Type Bussmann Bussmann Bussmann Bussmann Bussmann Bussmann
kW Type RK1 Type J Type T Type CC Type CC Type CC
K75-1K5 KTS-R-5 JKS-5 JJS-6 FNQ-R-5 KTK-R-5 LP-CC-5
2K2-4K0 KTS-R10 JKS-10 JJS-10 FNQ-R-10 KTK-R-10 LP-CC-10
5K5-7K5 KTS-R20 JKS-20 JJS-20 FNQ-R-20 KTK-R-20 LP-CC-20
FC Type SIBA Littel fuse
Ferraz-
Shawmut
kW Type RK1 Type RK1 Type RK1
K75-1K5 5017906-005 KLSR005 A6K-5R
2K2-4K0 5017906-010 KLSR010 A6K-10R
5K5-7K5 5017906-020 KLSR020 A6K-20R
FC Type Bussmann SIBA
Ferraz-
Shawmut
kW JFHR2 Type RK1 Type RK1
P37K 170M3013 2061032.125 6.6URD30D08A0125
P45K 170M3014 2061032.160 6.6URD30D08A0160
P55K 170M3015 2061032.200 6.6URD30D08A0200
P75K 170M3015 2061032.200 6.6URD30D08A0200
170M fuses shown from Bussmann use the -/80 visual indicator. –TN/80 Type T, -/110 or TN/110 Type T indicator fuses of the same size and
amperage may be substituted.
170M fuses from Bussmann when provided in the 525-600/690 V FC 302 P37K-P75K, FC 102 P75K, or P45K-P90K drives are 170M3015.
170M fuses from Bussmann when provided in the 525-600/690V FC 302 P90K-P132, FC 102 P90K-P132, or P110-P160 drives are 170M3018.
170M fuses from Bussmann when provided in the 525-600/690V FC 302 P160-P315, FC 102 P160-P315, or P200-P400 drives are 170M5011.
