6
4
5
3
2
1
e30bg470.11
1 LCP (Local control panel) 4 Screw (T20)
2 LCP cradle 5 Power card
3 Control card mounting plate 6 Power card mounting plate
Illustration 10.1 Control Card Mounting Plate
D1h/D3h/D5h/D6h/J8 Drive Di... Service Guide
MG94A502 Danfoss A/S © 02/2019 All rights reserved. 131
10 10
