1 Mixing fan release tab 4 Power terminal mounting plate
2 Cable connector 5 Cable access hole
3 Mixing fan 6 Mixing fan slot
Illustration 10.7 Mixing Fan
D1h/D3h/D5h/D6h/J8 Drive Di... Service Guide
MG94A502 Danfoss A/S © 02/2019 All rights reserved. 143
