1 Mixing fan release tab 4 Power terminal mounting plate
2 Cable connector 5 Cable access hole
3 Mixing fan 6 Mixing fan slot
Illustration 11.5 Mixing Fan
D2h/D4h/D7h/D8h/J9 Unit Dis... Service Guide
MG94A502 Danfoss A/S © 02/2019 All rights reserved. 199
11 11
