Danfoss VLT AutomationDrive FC 302

2
3
4
5
6
7
8
1
130BF864.10
1 Balance/high frequency card 5 DC center capacitor plate
2 Capacitor bank cover 6 DC(+) capacitor plate
3 DC(-) capacitor plate 7 Capacitor locking panel
4 Insulator sheet 8 DC capacitor
Illustration 11.7 Balance/High Frequency Card and DC Capacitor Bank (240/400 V unit shown, 690 V unit is similar.)
D2h/D4h/D7h/D8h/J9 Unit Dis...
VLT
®
FC Series, D1h–D8h, Da2/Db2/Da4/Db4, E1h–E4h, J8/J9
204 Danfoss A/S © 02/2019 All rights reserved. MG94A502
