Danfoss VLT AutomationDrive FC 302

Power
rating
Drive
type
Enclosure size Enclosure size with
extended options cabinet
Number of drive modules
N90K H D1h/D3h D5h/D6h –
N110 H D1h/D3h D5h/D6h –
N132 H D1h/D3h D5h/D6h –
N160 H D2h/D4h D7h/D8h –
N200 H D2h/D4h D7h/D8h –
N250 H D2h/D4h D7h/D8h –
N250 P6/P8 Db2 – 2-module system
N315 P6/P8 Db2 – 2-module system
N315 H E1h/E3h – –
N355 P6/P8 Db2 – 2-module system
N355 H E1h/E3h – –
N400 P6/P8 Db2 – 2-module system
N400 H E1h/E3h – –
N450 P2/P4 Da2 – 2-module system
N450 P6/P8 Db2 – 2-module system
N450 H E2h/E4h – –
N500 P2/P4 Da4 – 4-module system
N500 P6/P8 Db4 – 4-module system
N500 H E2h/E4h – –
N560 P2/P4 Da4 – 4-module system
N560 P6/P8 Db4 – 4-module system
N630 P2/P4 Da4 – 4-module system
N630 P6/P8 Db4 – 4-module system
N710 P2/P4 Da4 – 4-module system
N710 P6/P8 Db4 – 4-module system
N800 P2/P4 Da4 – 4-module system
N800 P6/P8 Db4 – 4-module system
Table 3.8 380–500 V AC (T5) Voltage Rating for FC 302
Product Overview Service Guide
MG94A502 Danfoss A/S © 02/2019 All rights reserved. 19
3 3
