130BF853.10
4
1
DC(+)
bus
rail
4
IGBT
cable
2
Gate
drive
card
5
DC(-)
bus
rail
3
Nut
(13
mm)
6
Screw
(
T40)
Illustration
11.12
DC
Bus
R
ails
with
Brake
Option
D2h/D4h/D7h/D8h/J9 Unit Dis...
Service Guide
MG94A502
Danfoss A/S © 02/2019 All rights reserved.
213
11
11
214
216
