Danfoss VLT AutomationDrive FC 302 Service Guide

1
2
5
8
10
3
9
6
7
130BF859.10
4
1 Balance/high frequency card 6 DC(-) plate
2 Capacitor bank cover 7 Insulator sheet
3 Screw (T25) 8 DC center capacitor plate
4 DC(+) plate 9 Capacitor locking plate
5 Insulator sheet 10 Standard DC capacitor
Illustration 11.14 Standard DC Capacitors, 400 V AC Unit
D2h/D4h/D7h/D8h/J9 Unit Dis... Service Guide
MG94A502 Danfoss A/S © 02/2019 All rights reserved. 217
11 11
