Danfoss VLT AutomationDrive FC 302

e30bg287.10
1
3
4
5
7
6
8
2
1 Door fan cable 5 Air direction arrow
2 Cable connector 6 Door fan
3 Nut (7 mm) 7 Hole for corner post
4 Door fan guard 8 Corner post
Illustration 11.34 Interior View of Door Fan Assembly
D2h/D4h/D7h/D8h/J9 Unit Dis...
VLT
®
FC Series, D1h–D8h, Da2/Db2/Da4/Db4, E1h–E4h, J8/J9
236 Danfoss A/S © 02/2019 All rights reserved. MG94A502
