Danfoss VLT AutomationDrive FC 302

1
2
3
130BF761.10
6
7
8
4
5
1 LCP 5 Ribbon cable and connector (under control card mounting plate)
2 LCP cradle 6 Screws (T20)
3 LCP cable connector 7 Power card
4 Control card 8 Control card mounting plate
Illustration 13.1 LCP and Control Card Mounting Plate
E1h–E4h Drive Disassembly a...
VLT
®
FC Series, D1h–D8h, Da2/Db2/Da4/Db4, E1h–E4h, J8/J9
262 Danfoss A/S © 02/2019 All rights reserved. MG94A502
1313
