Danfoss VLT AutomationDrive FC 302 Service Guide

1
2
3
4
5
130BF767.10
6
7
8
10
11
12
14
13
9
1 Nut (17 mm) in upper fuse 8 RFI lter
2 AC fuse 9 RFI cable access
3 Nut (17 mm) in lower fuse 10 Upper input plate
4 Disconnect 11 Nut (8 mm) in upper input plate
5 Nut (17 mm) at terminal L1 12 Lower input plate
6 Nut (30 mm) at upper RFI lter 13 Nut (8 mm) in lower input plate
7 AC input busbar 14 Nut (8 mm)
Illustration 13.9 Split Input Plate with Optional RFI Filter, AC Fuses, and Disconnect
E1h–E4h Drive Disassembly a...
VLT
®
FC Series, D1h–D8h, Da2/Db2/Da4/Db4, E1h–E4h, J8/J9
278 Danfoss A/S © 02/2019 All rights reserved. MG94A502
