Danfoss VLT AutomationDrive FC 302

130BF772.10
1
2
3
4
5
7
9
10
6
8
1 Gate drive card 6 Screw (T20)
2 MK501 7 Leg of mounting plate
3 MK100 8 IGBT output busbar
4 MK601 9 MK701
5 MK101 10 MK 201 (for brake option)
Illustration 13.12 Gate Drive Card Mounting Plate
E1h–E4h Drive Disassembly a...
VLT
®
FC Series, D1h–D8h, Da2/Db2/Da4/Db4, E1h–E4h, J8/J9
284 Danfoss A/S © 02/2019 All rights reserved. MG94A502
1313
