Danfoss VLT AutomationDrive FC 302 Service Guide

1
2
4
3
5
8
7
9
10
14
130BF837.10
6
11
12
13
1 Y-shaped busbar 8 Screw (T25)
2 Nut (13 mm) 9 Left motor busbar
3 Screw (T25) 10 Nut (13 mm)
4 IGBT motor busbar 11 Current sensor cable connector
5 Nut (13 mm) 12 Screw (T20)
6 Current sensor 13 Heat sink fan housing
7 Current sensor busbar 14 Right motor busbar
Illustration 13.15 E1h/E3h Motor Busbar Assembly (E2h/E4h is Similar)
E1h–E4h Drive Disassembly a...
VLT
®
FC Series, D1h–D8h, Da2/Db2/Da4/Db4, E1h–E4h, J8/J9
290 Danfoss A/S © 02/2019 All rights reserved. MG94A502
