Danfoss VLT AutomationDrive FC 302 Service Guide

2
1
3
4
5
6
130BF768.10
7
8
1 Front grill 5 Door fan front view
2 Release tab 6 Nut (7 mm)
3 Filter 7 Corner bracket
4 Screw (T20) 8 Door fan back view
Illustration 13.29 Door Fan Assembly
E1h–E4h Drive Disassembly a...
VLT
®
FC Series, D1h–D8h, Da2/Db2/Da4/Db4, E1h–E4h, J8/J9
308 Danfoss A/S © 02/2019 All rights reserved. MG94A502
