Danfoss VLT AutomationDrive FC 302

1
130BF769.10
2
3
4
5
6
1 Fan housing 4 Screw (T25)
2 Mounting pin (inside housing) 5 Cable access hole
3 Fan 6 Retaining clip
Illustration 13.30 Top Fan
E1h–E4h Drive Disassembly a...
