Frequency
converter
AC line
Motor cable
Motor
Stray capacitance
AC line
130BX140.12
Illustration 7.4 Alternate Signal Conductor Currents
Drive and Motor Application...
VLT
®
FC Series, D1h–D8h, Da2/Db2/Da4/Db4, E1h–E4h, J8/J9
86 Danfoss A/S © 02/2019 All rights reserved. MG94A502
