WARNING/ALARM 34, Fieldbus communication fault
The serial communication bus on the communication
option card is not working.
WARNING/ALARM 36, Mains failure
This warning/alarm is only active if the supply voltage to
the adjustable frequency drive is lost and 14-10 Mains
Failure is not set to [0] No Function. Check the fuses to the
adjustable frequency drive and line power supply to the
unit.
ALARM 38, Internal fault
When an internal fault occurs, a code number defined in
Table 9.2 is displayed.
Troubleshooting
Cycle power
Check that the option is properly installed
Check for loose or missing wiring
It may be necessary to contact Danfoss service or the
supplier. Note the code number for further trouble-
shooting directions.
No. Text
0 Serial port cannot be initialized. Contact your
Danfoss supplier or Danfoss Service Department
256–258 Power EEPROM data is defective or too old
512 Control board EEPROM data is defective or too old
513 Communication timeout reading EEPROM data
514 Communication timeout reading EEPROM data
515 Application-oriented control cannot recognize the
EEPROM data.
516 Cannot write to the EEPROM because a write
command is on progress
517 Write command is under timeout
518 Failure in the EEPROM
519 Missing or invalid barcode data in EEPROM
783 Parameter value outside of min/max limits
1024–1279 A CAN message that has to be sent could not be
sent
1281 Digital signal processor flash timeout
1282 Power micro software version mismatch
1283 Power EEPROM data version mismatch
1284 Cannot read digital signal processor software
version
1299 Option SW in slot A is too old
1300 Option SW in slot B is too old
1301 Option SW in slot C0 is too old
1302 Option SW in slot C1 is too old
1315 Option SW in slot A is not supported (not allowed)
1316 Option SW in slot B is not supported (not allowed)
1317 Option SW in slot C0 is not supported (not
allowed)
No. Text
1318 Option SW in slot C1 is not supported (not
allowed)
1379 Option A did not respond when calculating
platform version
1380 Option B did not respond when calculating
platform version
1381 Option C0 did not respond when calculating
platform version
1382 Option C1 did not respond when calculating
platform version
1536 An exception in the application-oriented control is
registered. Debug information written in LCP.
1792 DSP Watch Dog is active. Debugging of power
part data, motor-oriented control data not
transferred correctly.
2049 Power data restarted
2064–2072 H081x: Option in slot x has restarted
2080–2088 H082x: Option in slot x has issued a power-up wait
2096–2104 H983x: Option in slot x has issued a legal power-
up wait
2304 Could not read any data from power EEPROM
2305 Missing SW version from power unit
2314 Missing power unit data from power unit
2315 Missing SW version from power unit
2316 Missing lo_statepage from power unit
2324 Power card configuration is determined to be
incorrect at power-up
2325 A power card has stopped communicating while
line power is applied
2326 Power card configuration is determined to be
incorrect after the delay for power cards to
register
2327 Too many power card locations have been
registered as present.
2330 Power size information between the power cards
does not match.
2561 No communication from DSP to ATACD
2562 No communication from ATACD to DSP (state
running)
2816 Stack overflow control board module
2817 Scheduler slow tasks
2818 Fast tasks
2819 Parameter thread
2820 LCP stack overflow
2821 Serial port overflow
2822 USB port overflow
2836 cfListMempool too small
3072–5122 Parameter value is outside its limits
5123 Option in slot A: Hardware incompatible with
control board hardware
Warnings and Alarms Instruction Manual
134 Danfoss A/S © Rev. 2014-02-07 All rights reserved. MG37A222
