FC 300 Design Guide
How to Program
0-25 My Personal Menu
Array [20]
Range:
0 - 99 99
Function:
Defines the parameters to include in the Q1 Personal
Menu accessible via [Quick Menu] on the LCP. Add
up to 20 parameters in the Q1 Personal Menu.
The p arameters are listed in the Q1 Personal Menu
in the order programmed in this array parameter.
Delete parameters by setting the value to "0000".
" 0-4* LCP Keypad
0-40 [Hand on] K ey on LCP
Option:
Disabled [0]
*
Enabled [1]
Password [2]
Function:
Select Disabled [0] to avoid accidental s tart of
the drive in Hand mode. Selec t Password [2]
to avoid unauthorized start in Hand mode. Set
the password in par. 0-62 or par. 0-64 i f par.
0-40 is included in the Quick menu.
0-41 [Off] Key on LCP
Option:
D
isabled
[
0]
*
Enabled [1]
Password [2]
Function:
Press [Off] and select Disabled [0] to avoid
accidental drive stop. Press [Off] and select
Password [2] to avoid unauthorized stop. Set
the password in par. 0-62 or par. 0-64 i f par.
0-40 is included in the Quick menu.
0-42 [Auto on] Key on LCP
Option:
Disabled [0]
*
Enabled [1]
Password [2]
Function:
Press [Auto on] and select Disabled [0] to avoid
accidental drive start in Auto mode. Pre ss [Auto on]
and select Password [2 ] to avoid unauthorized start
in Auto mode. Set the password in par. 0-62 or par.
0-64 if par. 0-40 is included in the Quick menu.
0-43 [Reset] Key on LCP
Option:
Disabled [0]
*
Enabled [1]
Password [2]
Function:
Press [Reset] and select Disabled [0] to avoid
accidental alarm reset. Press [Reset] and select
Password [2] to avoid unauthorized resetting. Set
the password in par. 0-62 or par. 0-64 if par.
0-40 is included in the Quick menu.
" 0-5* Copy / Save
0-50 LCP Copy
Option:
*
No copy [0]
Transfer to LCP all parameters [1]
Transfer from LCP all parameters [2]
Transfer from LCP size indep.
parameters [3]
Function:
Select Transfer to LCP all parameters [1] to copy all
parameters in all set-ups from the drive memory
to the LCP memory. Select Transfer from LCP all
parameters [2] to copy all parameters in all set-ups
from the LCP me m ory to the drive m em ory. Select
Transfer from LCP size indep. parameters [3] to
copy only the parameters that are independent of
the motor size. The latter selection can be used
to program several drives with the same function
without disturbing m otor data whic h are already set.
0-51 Set-up Copy
Option:
*
No copy [0]
Copy to set-up 1 [1]
Copy to set-up 2 [2]
Copy to set-up 3 [3]
Copy to set-up 4 [4]
Copy to all [9]
Function:
Select Copy to set-up 1
[1] to copy all parameters
in the currently edited se t-up (set in par. 0-11)
*
default setting ()display text []value for use in communication via serial communication port
138
MG.33.B
3.22 - VLT is a registered Danfoss trademark
