FC 300 Design Guide
How to Program
16-92 Warning Word
16-93 Warning Word 2
16-94 Extended S tatus Word
16-95 Extended Status Word 2
Function:
Assigns different parameters to PCD 3 to 10 of
the PPOs (the number of PCDs depends on the
PPO type). PCD 3 to 10 holds the ac tual data
value of the selected parameters.
9-18 Node Address
Range:
0-126
*
126
Function:
Sets the station address. It is also possible to set it
on a hardware switch. Set the address in par. 9-18
only if the hardware switch is set to 126 or 127. The
parameter displays the actua l setting of the sw itch
when setting the hardware switch to >0 and <126.
Power-up or updating par. 9-72 changes par. 9-18.
9-22 Telegram S elect ion
Option:
Standard telegram 1 [1]
PPO 1 [101]
PPO 2 [102]
PPO 3 [103]
PPO 4 [104]
PPO 5 [105]
PPO 6 [106]
PPO 7 [107]
*
PPO 8 [108]
Function:
Insteadofusingpar. 9-15and9-16todefine
profibus telegrams freely, use standard telegrams
defined by the profibus profile. Standard Telegram 1
equals PPO type 3. This parameter is automatically
set to the according value (PPO type) when
the drive is configured by a PLC.
9-23 Parameters for Signals
Array [1000]
Option:
None
3-02 Minimum Reference
3-03 Maximum Reference
3-12 Catch Up/Slow Down Value
3-41 Ramp 1 Ramp Up Time
3-42 Ramp 1 Ramp Down Time
3-51 Ramp 2 Ramp Up Time
3-52 Ramp 2 Ramp Down Time
3-80JogRampTime
3-81 Quick Stop Ramp Rime
4-11 Motor Speed Low Limit
4-13 Motor S peed High Lim it
4-16 Torque Limit Motor Mode
4-17 Torque Limit Generator Mode
8-90 Bus Jog 1 Speed
8-91 Bus Jog 2 Speed
16-00 Control Word
16-01 Reference [Unit]
16-02 Reference %
16-03 S tatus Word
16-05 Main Actual Value [%]
16-10 Power [kW]
16-11 Power [hp]
16-12 Mo tor Voltage
16-13 Frequency
16-14 Motor Current
16-16 Torque
16-17 Speed [RPM]
16-18 Motor T hermal
16-19 KTY Sensor Tem perature
16-20 Phase Angle
16-30 DC Link Voltage
16-32 Brake Energy / s
16-33 Brake Energy / 2 Min
16-34 Heatsink Temp.
16-35 Inverter Thermal
16-38 SL Controller State
16-39 Controlcard Temp.
16-50 External Reference
16-51 Pulse Reference
16-52 Feedback [Unit]
16-53 Digi Pot Reference
16-60 Digital Input
16-61 Terminal 53 Switch Setting
16-62 Analog Input 53
16-63 Terminal 5
3SwitchSetting
16-64 Analog Input 54
16-65 Analog Output 42 [mA]
16-66 Digital
Output [bin]
16-67 Freq. Input #2 9 [Hz]
16-68 Freq. Input #3 3 [Hz]
16-69 Puls
e Output #27 [Hz]
16-70 Pulse Output #29 [Hz]
*
default setting ()display text []value for use in communication via serial communication port
187
MG.33.B
3.22 - VLT is a registered Danfoss trademark
