FC 300 Design Guide
How to Program
16-80 Fieldbus CTW 1
16-82 Fieldb u s REF 1
16-84 Comm Option STW
16-85 FC Port CTW 1
16-90 Alarm Word
16-91 Alarm Word 2
16-92 Warning Word
16-93 Warning Word 2
16-94 Extended S tatus Word
16-95 Extended Status Word 2
Function:
Contains a list of signals that can be entered
in par. 9-15 and 9-16. Furthe rmore, it
automatically s ets the parameters to meet the
most common requirements.
9-27 Parameter Edit
Option:
Disabled [0]
*
Enabled [1]
Function:
You can edit parameters via Profibus, the standard
RS-485 Interface, or the LCP. Disable editing
via Profibus with this parameter.
9-28 Process Control
Option:
Disable [0]
*
Enable cyclic master [1]
Function:
Process control (setting of Control Word, speed
reference, and process data) is possible via eit her
Profibus or the standard RS-485 Interface but not
both at the same time. Local control is always
possible vi a the LCP. Control via p rocess control is
possible with eithe r terminals or bus depending
on the s etting of par. 8-50 to 8-56.
- Disable: Disables process control via Profib us, and
enables proce ss control via standard RS-485.
- Enable cyclic master: Enables process control
via Profibus Master Class 1 , and disables process
control via standard RS-4 85 bus or Master class 2.
9-44 Fault Message Counter
Range:
0 - 65 535 N/A
*
0N/A
Function:
Indicates the number of alarms presently
stored in par. 9-47. The buffer capacity is
maximum eight error events.
9-45 Fault Code
Range:
0-0N/A
*
0N/A
Function:
This parameter contains the alarm word from
all alarm me ssages occurre d.
The buffer capacity is maximum eight error events.
9-47 Fault Number
Range:
0-0N/A
*
0N/A
Function:
This parameter conta ins the alarm number
(e.g. 2 for live zero error, 4 for line phase
loss) that occurs for an event.
The buffer capacity is maximum eight error events.
9-52 Fault Situation Counter
Range:
0 - 1000 N/A
*
0N/A
Function:
This parameter contains the number of events
presently stored since last reset/p ower-up.
Par. 9-52 is incremented for every event
(by AOC or Profibus option).
*
default setting ()display text []value for use in communication via serial communication port
