FC 300 Design Guide
How to Program
9-53 Profibus Warning Word
Option:
Bit: Meaning:
0 Connection with DP master is not
1 Timeout action active
2 FDL (Field-bus Data link Layer) is not ok
3 Clear data command received
4 Actual value is not updated
5baudratesearch
6 PROFIBUS ASIC is not transmitting
7 Initializing of PROFIBUS is not ok
8 drive is tripped
9 internal CAN error
10 wrong ID sent by PLC
11 Internal error occurred
12 not configured
13 clear command received
14 warning 34 active
Function:
Displays Profibus communication warnings.
9-63 Actual Baud Rate
Option:
Read-only
9.6 kbit/s [0]
19.2 kbit/s [1]
93.75 kbit/s [2]
187.5 kbit/s [3]
500 kbit/s [4]
1500 kbit/s [6]
3000 kbit/s [7]
6000 kbit/s [8]
12000 kbit/s [9]
31.25 kbit/s [10]
45.45 kbit/s [11]
No baud rate found [255]
Function:
Displays the actual PROFIBUS baud rate. The
Profibus Master automatically set s the baud rate.
9-64 Device Identification
Array [10]
Option:
Read only
Array [10]
Index Content Value
[0] manufacturer 128 (for Danfoss)
[1] device type 1
[2] version xxyy
[3] firmware date year yyyy
[4] firmware date month ddmm
[5] no. of axes variable
[6] vendor specific :PB
Version
xxyy
[7] vendor-specific :
Database Version
xxyy
[8] vendor-specific :
AOC Version
xxyy
[9] vendor-specific :
MOC Version
xxyy
Function:
The dev ice identification parameter. The
data type is "Array[n] o f Unsigned16". The
assignment of the first subindexes is d efine d
and shown in the table above.
9-65 Profile Number
Option:
Read only
0-0
*
0
Function:
Contains the profile identification. Byte 1
contains the profile number and byte 2 the
version number of the profile.
9-71 Save Data Values
Option:
*
Off [0]
Store edit setup [1]
Store all set-ups [2]
Function:
Parameter values changed via Profibus are not
automatically stored into non-volatile mem ory. Use
this parameter to activate a function that stores all
parameter values in the EEPROM. Thus, you retain
changed parameter values at power-down.
*
default setting ()display text []value for use in communication via serial communication port
189
MG.33.B
3.22 - VLT is a registered Danfoss trademark
