9.3 Active Filter Parameter Lists
9.3.1 Default settings
Changes during operation:
”TRUE” means that the parameter can be changed while the active lter is in operation and “FALSE” means that the unit
must be stopped before a change can be made.
4 set-up:
'All set-up': the parameter can be set individually in each of the four set-ups, i.e., one single parameter can have four
dierent data values.
’1 set-up’: the data value will be the same in all set-ups.
SR:
Size related
N/A:
No default value available.
Conversion index:
This number refers to a conversion gure used when writing or reading using an active lter.
Conv.
index
100 75 74 70 67 6 5 4 3 2 1 0 -1 -2 -3 -4 -5 -6
Conv.
factor
1 3,600,00
0
3,60
0
60 1/60 1,000,0
00
100,00
0
10,00
0
1,000 100 10 1 0.1 0.01 0.001 0.000
1
0.00001 0.00000
1
Table 9.1 Conversion Index
Data type Description Type
2 Integer 8 Int8
3 Integer 16 Int16
4 Integer 32 Int32
5 Unsigned 8 Uint8
6 Unsigned 16 Uint16
7 Unsigned 32 Uint32
9 Visible String VisStr
33 Normalized value 2 bytes N2
35 Bit sequence of 16 Boolean variables V2
54 Time dierence w/o date TimD
Table 9.2 Data Type and Description
Appendix A - Parameters
VLT
®
AutomationDrive FC 302 Low Harmonic Drive
132–630 kW
112 Danfoss A/S © Rev. 04/2015 All rights reserved. MG37A322
