Danfoss VLT AutomationDrive FC 302 Installation Manual

8 Specications
8.1 Power-Dependent Specications
8.1.1 Line Power Supply 3x380–480 V AC
P132 P160 P200
Normal Overload =110% current for 60 s HO NO HO NO HO NO
Typical shaft output at 400 V [kW] 132 160 160 200 200 250
Typical shaft output at 460 V [hp] 200 250 250 300 300 350
Typical shaft output at 480 V [kW] 160 200 200 250 250 315
Enclosure IP21/54 D13
Output current
Continuous (at 400 V) [A] 260 315 315 395 395 480
Intermittent (60 s overload) (at 400 V) [A] 390 347 473 435 593 528
Continuous (at 460/480 V) [A] 240 302 302 361 361 443
Intermittent (60 s overload) (at 460/480 V)
[A]
360 332 453 397 542 487
Continuous kVA (at 400 V) [kVA] 180 218 218 274 274 333
Continuous kVA (at 460 V) [kVA] 191 241 241 288 288 353
Continuous kVA (at 480 V) [kVA] 208 262 262 313 313 384
Max. Input current
Continuous (at 400 V) [A] 251 304 304 381 381 463
Continuous (at 460/480 V) [A] 231 291 291 348 348 427
Max. pre-fuses
1)
[A]
400 500 630
Max. cable size
Motor (mm
2
/AWG
2)
)
2x185 (2x300 mcm)
Line power (mm
2
/AWG
2)
)
Load sharing (mm
2
/AWG
2)
)
Brake (mm
2
/AWG
2)
)
Total LHD loss 400 V AC [kW] 7621 8868 8594 10527 10003 11751
Total backchannel loss 400 V AC [kW] 6136 7318 7067 8903 8398 10033
Total lter loss 400 V AC [kW] 4505 4954 4954 5714 5714 6234
Total LHD loss 460 V AC [kW] 7687 9059 8799 10192 9714 11706
Total backchannel loss 460 V AC [kW] 5819 7123 6883 8209 7747 9635
Total lter loss 460 V AC [kW] 4801 5279 5279 5819 5819 6681
Weight, enclosure IP21, IP54 (lbs [kg]) 838 [380] 896 [406]
Eciency
4)
0.96
Output frequency [Hz] 0–800
Heatsink overtemp. trip (°F [°C]) 221 [105]
Power card ambient trip (°F [°C]) 185 [85]
*High overload = 160% torque during 60 s; Normal overload = 110% torque during 60 s
Table 8.1 Line Power Supply 3x380–480 V AC
Specications
VLT
®
AutomationDrive FC 302 Low Harmonic Drive
132–630 kW
86 Danfoss A/S © Rev. 04/2015 All rights reserved. MG37A322
