Danfoss VLT AutomationDrive FC 302

9.3.3 Digital In/Out 5-**
Par.
No. #
Parameter description Default value 4-set-up FC 302
only
Change
during
operation
Conver-
sion
index
Type
5-0* Digital I/O mode
5-00 Digital I/O Mode [0] PNP All set-ups FALSE - Uint8
5-01 Terminal 27 Mode [0] Input All set-ups TRUE - Uint8
5-02 Terminal 29 Mode [0] Input All set-ups x TRUE - Uint8
5-1* Digital Inputs
5-10 Terminal 18 Digital Input [8] Start All set-ups TRUE - Uint8
5-11 Terminal 19 Digital Input [0] No operation All set-ups TRUE - Uint8
5-12 Terminal 27 Digital Input [0] No operation All set-ups TRUE - Uint8
5-13 Terminal 29 Digital Input [0] No operation All set-ups TRUE - Uint8
5-14 Terminal 32 Digital Input [90] AC Contactor All set-ups TRUE - Uint8
5-15 Terminal 33 Digital Input [91] DC Contactor All set-ups TRUE - Uint8
5-16 Terminal X30/2 Digital Input [0] No operation All set-ups TRUE - Uint8
5-17 Terminal X30/3 Digital Input [0] No operation All set-ups TRUE - Uint8
5-18 Terminal X30/4 Digital Input [0] No operation All set-ups TRUE - Uint8
5-19 Terminal 37 Safe Stop [1] Safe Stop Alarm 1 set-up TRUE - Uint8
5-3* Digital Outputs
5-30 Terminal 27 Digital Output [0] No operation All set-ups TRUE - Uint8
5-31 Terminal 29 Digital Output [0] No operation All set-ups x TRUE - Uint8
5-4* Relays
5-40 Function Relay [0] No operation All set-ups TRUE - Uint8
5-41 On Delay, Relay 0.30 s All set-ups TRUE -2 Uint16
5-42 O Delay, Relay 0.30 s All set-ups TRUE -2 Uint16
Appendix A - Parameters
VLT
®
AutomationDrive FC 302 Low Harmonic Drive
132–630 kW
114 Danfoss A/S © Rev. 04/2015 All rights reserved. MG37A322
