Danfoss VLT AutomationDrive FC 302

Bottom view, F18
2
3
5
6
130BC587.10
4
1
1 Mains cable entry 4 Motor cable entry
2 Option enclosure 5 Inverter enclosure
3 Filter enclosure 6 Rectier enclosure
Figure 3.12 Cable Entry Diagram, F18
Installation
VLT
®
AutomationDrive FC 302 Low Harmonic Drive
132–630 kW
