5.1.1. Product Specification:
380-500 Volt
VLT Type P110 P132 P160 P200
Output current [VAC] HO NO HO NO HO NO HO NO
Continuous (100/ 100%) [A] 400 212 260 260 315 315 395 395 480
Intermittent (150/ 110%) [A] 400 318 286 390 347 473 435 593 528
Continuous (100/ 100%) [A] 460/ 500 190 240 240 302 302 361 361 443
Intermittent (150/ 110%) [A] 460/ 500 285 264 360 332 453 397 542 487
Output kVA
Continuous (100/ 100%) [kVA] 400 147 180 180 218 218 274 274 333
Intermittent (150/ 110%) [kVA] 400 220 198 270 240 327 301 410 366
Continuous (100/ 100%) [kVA] 460 151 191 191 241 241 288 288 353
Intermittent (150/ 110%) [kVA] 460 227 210 287 265 361 316 431 388
Continuous (100/ 100%) [kVA] 500 165 208 208 262 262 313 313 384
Intermittent (150/ 110%) [kVA] 500 247 229 312 288 392 344 469 422
Typical Shaft Output
High Overload (150%) [kW] 400 110 132 160 200
Normal Overload (110%) [kW] 400 132 160 200 250
High Overload (150%) [HP] 460 150 200 250 300
Normal Overload (110%) [HP] 460 200 250 300 350
High Overload (150%) [kW] 500 132 160 200 250
Normal Overload (110%) [kW] 500 160 200 250 315
Max. Motor Cable Length 500 ft (150 m) shielded, 1,000 ft (300 m) un-
shielded
Output Voltage [%] 0-100% of the AC line voltage
Output Frequency [Hz] 0-450
Rated Motor Voltage [V] 400/460/500
Rated Motor Frequency [Hz] 50/60
Thermal protection during
operation
ETR for motor (Class 20)
Thermal protection during
operation
Deg C.
VLT trip
90
VLT trip
105
VLT trip
105
VLT trip
115
Switching on the Output Unlimited
Ramp times [sec]
0.01 - 3600
VLT
®
Automation Drive FC 300
Instruction Manual High Power
5. General Specifications
MG.33.U1.22 - VLT
®
is a registered Danfoss trademark. 117
5

Danfoss VLT FC 100 Specifications

General
