Danfoss VLT FC 100 User Manual

380-500 Volt
VLT Type P250 P315 P355 P400
Output current [VAC] HO NO HO NO HO NO HO NO
Continuous (100/ 100%) [A] 400 480 600 600 658 658 745 695 800
Intermittent (150/ 110%) [A] 400 720 660 900 724 987 820 1043 880
Continuous (100/ 100%) [A] 460/ 500 443 540 540 590 590 678 678 730
Intermittent (150/ 110%) [A] 460/ 500 665 594 810 649 885 746 1017 803
Output kVA
Continuous (100/ 100%)
[kVA]
400 333 416 416 456 456 516 482 554
Intermittent (150/ 110%)
[kVA]
400 499 457 624 501 684 568 723 610
Continuous (100/ 100%)
[kVA]
460 353 430 430 470 470 540 540 582
Intermittent (150/ 110%)
[kVA]
460 529 473 645 517 705 594 810 640
Continuous (100/ 100%)
[kVA]
500 384 468 468 511 511 587 587 632
Intermittent (150/ 110%)
[kVA]
500 575 514 701 562 766 646 881 695
Typical Shaft Output
High Overload (150%) [kW] 400 250 315 355 400
Normal Overload (110%)
[kW]
400 315 355 400 450
High Overload (150%) [HP] 460 350 450 500 550
Normal Overload (110%)
[HP]
460 450 500 600 600
High Overload (150%) [kW]
500 315 355 400 500
Normal Overload (110%)
[kW]
500 355 400 500 530
Max. Motor Cable Length 500 ft (150 m) shielded, 1,000 ft (300 m) unshielded
Output Voltage [%] 0-100% of the AC line voltage
Output Frequency [Hz] 0-300 0-200
Rated Motor Voltage [V] 400/460/500
Rated Motor Frequency
[Hz]
50/60
Thermal protection during
operation
ETR for motor (Class 20)
Thermal protection during
operation
Deg C. VLT trip at 203° F [95° C]
Switching on the Output Unlimited
Ramp times [sec] 0.01 - 3600
VLT
®
Automation Drive FC 300
Instruction Manual High Power
5. General Specifications
MG.33.U1.22 - VLT
®
is a registered Danfoss trademark. 119
