Danfoss VLT FC Series User Manual

1.6.5 Option Panel Voltage and Frame
Ratings
Table 1.4 to Table 1.10 define the voltage and hp ratings of
the frames sizes for the option panel. See the mechanical
drawing shipped with the unit for dimensions.
FC 102/202 FC 302
[V AC] [hp] [hp]
208-230 1.5-5 1.5-5
460-480 1.5-10 1.5-10
575-600 1.5-10 1.5-10
Table 1.4 Frames A2 to A5
FC 102/202 FC 302
[V AC] [hp] [hp]
208-230 7.5-15 7.5-15
460-480 15-25 15-20
575-600 15-25 15-20
Table 1.5 Frame B1
FC 102/202 FC 302
[V AC] [hp] [hp]
208-230 15-20 15
460-480 30-40 25-30
575-600 30-40 25-30
Table 1.6 Frame B2
FC 102/202 FC 302
[V AC] [hp] [hp]
208-230 25-30 20-30
460-480 50-75 40-60
575-600 50-75 40-60
Table 1.7 Frame C1
FC 102/202 FC 302
[V AC] [hp] [hp]
208-230 40-60 40-50
460-480 100-125 75-100
575-600 100-125 75-100
Table 1.8 Frame C2
FC 102/202 FC 302
[V AC] [hp] [hp]
460-480 150-200 125-150
575-600 150-200 125-150
Table 1.9 Frame D1
FC 102/202 FC 302
[V AC] [hp] [hp]
460-480 250-350 200-300
575-600 250-400 200-350
Table 1.10 Frame D2
Introduction Option Panel Operating Instructions
MG14I102 - VLT
®
is a registered Danfoss trademark 9
1 1

Danfoss VLT FC Series Specifications

General

Category	DC Drives
Series	VLT FC Series
Output Voltage	0-100% of input voltage
Protection Features	Overvoltage, Undervoltage, Overcurrent, Short circuit, Overtemperature, Motor overload
Communication Interfaces	CANopen, PROFIBUS, Ethernet
Cooling Method	liquid-cooled
Enclosure Rating	IP20, IP21, IP55
Ambient Temperature	-10°C to +40°C (14°F to 104°F) without derating
