3.4.3 Wire Size
NOTE
MAKE ALL POWER CONNECTIONS WITH MINIMUM 75 °C/167 °F RATED COPPER WIRING FOR INSTALLATIONS IN NORTH
AMERICA.
•
Size field wiring to NEC and local code requirements. The maximum allowable field wire size for any option panel
is shown in Table 3.8 through Table 3.15
Disc. W/O Mains Fusing Disc. W Mains Fusing Disc. W 100KIA SCCR Circuit Breaker
Type Code Char CHAR 15&16 CHAR 15&16 CHAR 15&16 CHAR 15&16
Type Code MD,ND MM,NM MN,NN CD,FD
[HP] Terminal Cap. [AWG] Terminal Cap. [AWG] Terminal Cap. [AWG] Terminal Cap. [AWG]
0.50 8 4 8 10
0,75 8 4 8 10
1 8 4 8 10
1.5 8 4 8 10
2 8 4 8 10
3 8 4 8 10
5 8 4 8 10
7.50 8 4 4 3
10 8 4 4 3
15 3 4 3 2
20 3 3 3 2
25 1/0 1/0 1/0 1/0
30 1/0 1/0 1/0 300KCM
40 300KCM 300KCM 300KCM 300KCM
50 300KCM 300KCM 300KCM 300KCM
60 300KCM 300KCM 300KCM 300KCM
Table 3.8 208 V Max Wire - Input
Installation Option Panel Operating Instructions
MG14I102 - VLT
®
is a registered Danfoss trademark 19
