OL1 - Single Motor OL1 - Dual Motor OL2 - Dual Motor CMS - M4 & M5 MT1 TB 0R LUG (ECB)
Type Code Char CHAR 20 CHAR 20 CHAR 20 CHAR 20 CHAR 13&14&18
Type Code S D D C NO&D
[HP] Terminal Cap. [AWG] Terminal Cap. [AWG] Terminal Cap. [AWG] Terminal Cap. [AWG] Terminal Cap. [AWG]
0.50 8 N/A N/A 10 12
0.75 8 N/A N/A 10 12
1 8 N/A N/A 10 12
1.5 8 8 8 10 12
2 8 8 8 10 12
3 8 8 8 10 12
5 8 8 8 10 4
7.5 8 8 8 8 4
10 8 8 8 8 4
15 1/0 8 8 1/0 4
20 1/0
8 (0.50-10HP) 8 (0.50-10HP)
1/0 4
1/0 (15-30HP) 8 (0.50-10HP)
25 1
8 (0.50-10HP) 8 (0.50-10HP)
1/0 1
1 (15-30HP) 8 (0.50-10HP)
30 1 1 (15-30HP) 8 (0.50-10HP) 1/0 1
40 4/0
1/0 (15-30HP) 8 (0.50-10HP)
4/0 250 KCM
1/0 (15-30HP) 1/0 (15-30HP)
50 4/0
1/0 (15-30HP) 8 (0.50-10HP)
4/0 250 KCM1/0 (15-30HP) 1/0 (15-30HP)
4/0 (40-60HP) 8 (0.50-10HP)
60 4/0
1/0 (15-30HP) 1/0 (15-30HP)
4/0 2/0 (DUAL)4/0 (40-60HP) 8 (0.50-10HP)
4/0 (40-60HP) 1/0 (15-30HP)
Table 3.9 208 V Max Wire - Output
Disc. W/O Mains Fusing Disc. W Mains Fusing Disc. W 100KIA SCCR Circuit Breaker
Type Code Char CHAR 15&16 CHAR 15&16 CHAR 15&16 CHAR 15&16
Type Code MD,ND MM,NM MN,NN CD,FD
[HP] Maximum Wire Size [AWG] Maximum Wire Size [AWG] Maximum Wire Size [AWG] Maximum Wire Size [AWG]
0.50 8 4 8 10
0.75 8 4 8 10
1 8 4 8 10
1.5 8 4 8 10
2 8 4 8 10
3 8 4 8 10
5 8 4 8 10
7.5 8 4 4 3
10 8 4 4 3
15 3 4 3 2
20 3 4 3 2
25 1/0 1/0 1/0 1/0
30 1/0 1/0 1/0 1/0
40 300KCM 300KCM 300KCM 300KCM
50 300KCM 300KCM 300KCM 300KCM
60 300KCM 300KCM 300KCM 300KCM
Table 3.10 230 V Max Wire - Input
Installation Option Panel Operating Instructions
20 MG14I102 - VLT
®
is a registered Danfoss trademark
3
3
