Danfoss VLT FC Series User Manual

Disc. W/O Mains Fusing Disc. W Mains Fusing Disc. W 100KIA SCCR Circuit Breaker
Type Code Char CHAR 15&16 CHAR 15&16 CHAR 15&16 CHAR 15&16
Type Code MD,ND MM,NM MN,NN CD,FD
[HP] Maximum Wire Size [AWG] Maximum Wire Size [AWG] Maximum Wire Size [AWG] Maximum Wire Size [AWG]
0.50 8 4 8 10
0.75 8 4 8 10
1 8 4 8 10
1.5 8 4 8 10
2 8 4 8 10
3 8 4 8 10
5 8 4 8 10
7.5 8 4 8 10
10 8 4 8 10
15 8 4 8 3
20 8 4 4 3
25 8 4 4 3
30 8 4 4 2
40 3 4 4 2
50 1/0 1/0 1/0 1/0
60 1/0 1/0 1/0 1/0
75 1/0 1/0 1/0 300KCM
100 300KCM 1/0 1/0 300KCM
125 300KCM 300KCM 300KCM 300KCM
150 250 KCM 250 KCM 250 KCM 2/0 (DUAL)
200 250 KCM (DUAL) 250 KCM (DUAL) 250 KCM (DUAL) 2/0 (DUAL)
250 250 KCM (DUAL) 250 KCM (DUAL) 250 KCM (DUAL) 250 KCM (DUAL)
300 250 KCM (DUAL) 250 KCM (DUAL) 250 KCM (DUAL) 250 KCM (DUAL)
350 250 KCM (DUAL) 250 KCM (DUAL) 250 KCM (DUAL) 250 KCM (DUAL)
400 350 KCM (DUAL) 350 KCM (DUAL) 350 KCM (DUAL) 250 KCM (DUAL)
Table 3.14 600 V Max Wire - Input
Installation Option Panel Operating Instructions
24 MG14I102 - VLT
®
