Input Conn. Term. Function Type
X57
1 Digital input for safety stop User supplied dry contact
2 Common User supplied dry contact
3 Factory use only
4 No function
5 Factory use only
6 Factory use only
7 Factory use only
8 Digital input for remote bypass enable User supplied dry contact
9 Digital input overrides system to Bypass Mode ignoring all
other inputs and commands, except for safety stop on
terminal 1.
User supplied dry contact
10 Digital input for remote overload reset User supplied dry contact
Output Conn. Term. Function
X59
1 Common for binary I/O
2 Common for binary I/O
3 No function
4 No function
5 Digital output indicates panel is in Drive Mode. 24 V DC digital output
6 Digital output indicates panel is in Bypass Mode 24 V DC digital output
7 Common for binary I/O
8 Common for binary I/O
Relay Output Term. Function
X56
1 N.O. contact for running in bypass or drive Relay output for user
2 N.O. contact for running in bypass or drive Relay output for user
3-12 Factory use only
Table 6.5 ECB Card Terminals
Electronically Controlled B... Option Panel Operating Instructions
MG14I102 - VLT
®
is a registered Danfoss trademark 47
