8-52 DC Brake Select
Option: Function:
[3] Logic OR Activates start command via the fieldbus/serial
communication port OR via one of the digital
inputs.
8-53 Start Select
Option: Function:
Select control of the frequency converter start
function via the terminals (digital input) and/or
via the fieldbus.
[0] Digital
input
Activates a start command via a digital input.
[1] Bus Activates a start command via the serial
communication port or fieldbus option.
[2] Logic
AND
Activates a start command via the fieldbus/serial
communication port, AND additionally via one
of the digital inputs.
[3] * Logic OR Activates a start command via the fieldbus/serial
communication port OR via one of the digital
inputs.
8-54 Reversing Select
Option: Function:
[0] Digital
input
Select control of the frequency converter
reverse function via the terminals (digital input)
and/or via the fieldbus.
[1] Bus Activates the reverse command via the serial
communication port or fieldbus option.
[2] Logic
AND
Activates the reverse command via the
fieldbus/serial communication port, AND
additionally via one of the digital inputs.
[3] * Logic OR Activates the reverse command via the
fieldbus/serial communication port OR via one
of the digital inputs.
8-55 Set-up Select
Option: Function:
Select control of the frequency converter set-up
selection via the terminals (digital input) and/or
via the fieldbus.
[0] Digital
input
Activates the set-up selection via a digital input.
[1] Bus Activates the set-up selection via the serial
communication port or fieldbus option.
[2] Logic
AND
Activates the set-up selection via the fieldbus/
serial communication port, AND additionally via
one of the digital inputs.
[3] * Logic OR Activate the set-up selection via the fieldbus/
serial communication port OR via one of the
digital inputs.
8-56 Preset Reference Select
Option: Function:
Select control of the preset reference selection
via the terminals (digital input) and/or via the
fieldbus.
[0] Digital
input
Activates preset reference selection via a digital
input.
[1] Bus Activates preset reference selection via the
serial communication port or fieldbus option.
[2] Logic
AND
Activates preset reference selection via the
fieldbus/serial communication port, AND
additionally via one of the digital inputs.
[3] * Logic OR Activates the preset reference selection via the
fieldbus/serial communication port OR via one
of the digital inputs.
8-90 Bus Jog 1 Speed
Range: Function:
100 RPM* [ 0 - par. 4-13
RPM]
Enter the jog speed. Activate this
fixed jog speed via the serial port
or fieldbus option.
8-91 Bus Jog 2 Speed
Range: Function:
200 RPM* [ 0 - par. 4-13
RPM]
Enter the jog speed. Activate this
fixed jog speed via the serial port
or fieldbus option.
6.2 9-** and 16-** PROFIBUS Parameters
9-15 PCD Write Configuration
Array [10]
Option: Function:
Select the parameters
to be assigned to PCD
3 to 10 of the
telegrams. The number
of available PCDs
depends on the
telegram type. The
values in PCD 3 to 10
are then written to the
selected parameters as
data values. Alterna-
tively, specify a
standard PROFIBUS
telegram in
9-22 Telegram
Selection.
[0] None
[302] Minimum Reference
[303] Maximum Reference
[312] Catch up/slow Down Value
[341] Ramp 1 Ramp Up Time
Parameters Programming Guide
MG37G102 Danfoss A/S © Rev. 05/2014 All rights reserved. 35
6 6
