6.3 PROFIBUS-specific Parameter List
Parameter Default value Range Conversion index Data type
8-01 Control Site
[0] Dig. & ctrl. word [0-2] - Uint8
Parameter 8-02 Control Word Source
[0] FC RS485 [0-4] - Uint8
Parameter 8-03 Control Word Timeout Time
1 0.1-18000 -1 Uint32
Parameter 8-04 Control Word Timeout Function
[0] Off [0-10] - Uint8
8-05 End-of-Timeout Function
[0] Hold set-up [0-1] - Uint8
Parameter 8-06 Reset Control Word Timeout
[0] Do not reset [0-1] - Uint8
Parameter 8-07 Diagnosis Trigger
[0] Disable [0-3] - Uint8
Parameter 8-10 Control Word Profile
[0] FC profile [0-x] - Uint8
8-50 Coasting Select
*[3] Logic OR [0-3] - Uint8
Parameter 8-51 Quick Stop Select
*[3] Logic OR [0-3] - Uint8
8-52 DC Brake Select
*[3] Logic OR [0-3] - Uint8
8-53 Start Select
*[3] Logic OR [0-3] - Uint8
Parameter 8-54 Reversing Select
*[3] Logic OR [0-3] - Uint8
8-55 Set-up Select
*[3] Logic OR [0-3] - Uint8
8-56 Preset Reference Select
*[3] Logic OR [0-3] - Uint8
8-90 Bus Jog 1 Speed
100 rpm 0-par. 4-13 67 Uint16
8-91 Bus Jog 2 Speed
200 rpm 0-par. 4-13 67 Uint16
Parameter 9-15 PCD Write Configuration
- - - Uint16
Parameter 9-16 PCD Read Configuration
- - - Uint16
9-18 Node Address
126 1-126 0 Uint8
9-22 Telegram Selection
- [0-108] - Uint8
Parameter 9-23 Parameters for Signals
- 0-573 - Uint16
9-27 Parameter Edit
[1] Enabled [0-1] - Uint16
9-28 Process Control
[1] Enable cyclic master [0-1] - Uint16
9-44 Fault Message Counter
0 [0-8] 0 Uint16
9-45 Fault Code
0 - - Uint16
9-47 Fault Number
0 - - Uint16
9-52 Fault Situation Counter
0 0-1000 0 Uint16
9-53 Profibus Warning Word
0 16 bits 0 V2
9-63 Actual Baud Rate
[255] No baud rate found 9.6-12000 kbits 0 Uint8
Parameter 9-64 Device Identification
0 [0-10] 0 Uint16
9-65 Profile Number
0 8 bits 0 Uint8
9-70 Edit Set-up
[9] Active set-up [0-9] - Uint8
9-71 Profibus Save Data Values
[0] Off [0-2] - Uint8
9-72 ProfibusDriveReset
[0] No action [0-2] - Uint8
9-80 Defined Parameters (1)
- 0-115 0 Uint16
9-81 Defined Parameters (2)
0-115 0 Uint16
9-82 Defined Parameters (3)
- 0-115 0 Uint16
9-83 Defined Parameters (4)
- 0-115 0 Uint16
9-90 Changed Parameters (1)
- 0-115 0 Uint16
9-91 Changed Parameters (2)
- 0-115 0 Uint16
9-92 Changed Parameters (3)
- 0-115 0 Uint16
9-93 Changed Parameters (4)
- 0-115 0 Uint16
16-84 Comm. Option STW
0 0-FFFF 0 V2
16-90 Alarm Word
0 0-FFFF 0 Uint32
16-92 Warning Word
0 0-FFFF 0 Uint32
Table 6.2 PROFIBUS-specific Parameter List
Refer to the relevant operating instructions for a comprehensive parameter list.
