Program the frequency converter as in Table 7.2:
Parameter Setting
4-10 Motor Speed Direction [2] Both directions
5-10 Terminal 18 Digital Input [0] No operation
5-11 Terminal 19 Digital Input [10] Reversing
5-40 Function Relay [36/37] Control word bit 11/12
parameter 8-03 Control Word Timeout Time
1 s
parameter 8-04 Control Word Timeout Function [2] Stop
parameter 8-10 Control Word Profile [0] FC Profile
8-50 Coasting Select [1] Bus
parameter 8-51 Quick Stop Select [1] Bus
8-52 DC Brake Select [1] Bus
8-53 Start Select [1] Bus
parameter 8-54 Reversing Select [2] Logic AND
8-55 Set-up Select [1] Bus
8-56 Preset Reference Select [1] Bus
parameter 9-16 PCD Read Configuration [2] Sub index 16-16 Torque [Nm]
[3] Sub index 16-60 Digital Input
9-18 Node Address
Set the address
Table 7.2 Parameter Settings
7.2
Example 2: Control Word Telegram using PPO Type
This example shows how the control word telegram relates to the PLC and the frequency converter, using FC control profile.
The control word telegram is sent from the PLC to the frequency converter. PPO Type 3 is used in the example to
demonstrate the full range of modules. All the values shown are arbitrary, and are provided for demonstration purposes
only.
Table 7.3 indicates the bits contained within the control word, and how they are presented as process data in PPO type 3
for this example.
PCV PCD
1 2 3 4 5 6
PCA IND PVA CTW MRV PCD PCD PCD PCD
04 7C 20 00
PQW 256 258 260 262 264 266 268 270 272 274
master slave CTW MRV
Bit no. 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
0 0 0 0 0 1 0 0 0 1 1 1 1 1 0 0
0 4 7 C
Table 7.3 Example: Control Word Telegram using PPO Type
Table 7.4 indicates the bit functions and corresponding bit values which are active for this example.
Application Examples
Programming Guide
44 Danfoss A/S © Rev. 05/2014 All rights reserved. MG37G102
