Danfoss VLT HVAC Basic Drive FC 101 Programming Guide

Parameter 1-10 Motor
Construction
[0]
Asynchron
[1] PM,
non-
salient
SPM
[3] PM,
salient
IPM,
Sat.
Parameter 4-19 Max Output
Frequency
x x x
Parameter 4-58 Missing Motor
Phase Function
x x x
Parameter 14-01 Switching
Frequency
x x x
Parameter 14-03 Overmodulation x x x
Parameter 14-07 Dead Time
Compensation Level
x x x
Parameter 14-08 Damping Gain
Factor
x x x
Parameter 14-09 Dead Time Bias
Current Level
x x x
Parameter 14-10 Mains Failure x x x
Parameter 14-11 Mains Fault
Voltage Level
x x x
Parameter 14-12 Function at
Mains Imbalance
x x x
Parameter 14-27 Action At
Inverter Fault
x x x
Parameter 14-40 VT Level x x x
Parameter 14-41 AEO Minimum
Magnetisation
x x x
Parameter 14-44 d-axis current
optimization for IPM
x
Parameter 14-50 RFI Filter x
Parameter 14-51 DC-Link Voltage
Compensation
x x x
Parameter 14-55 Output Filter x x x
Parameter 14-64 Dead Time
Compensation Zero Current Level
x x x
Parameter 14-65 Speed Derate
Dead Time Compensation
x x x
Parameter 30-22 Locked Rotor
Protection
x x
Parameter 30-23 Locked Rotor
Detection Time [s]
x x
Table 3.2 Active Parameters
1-10 Motor Construction
Option: Function:
[0] * Asynchron For asynchronous motors.
[1] PM, non-
salient SPM
For permanent magnet (PM) motors with
surface-mounted (non-salient) magnets.
Refer to parameter 1-14 Damping Gain to
parameter 1-17 Voltage lter time const. for
details about optimizing the motor
operation.
[3] PM, salient
IPM, Sat.
For permanent magnet (PM) motors with
interior (salient) magnets, with inductance
saturation control.
3.2.3
1-14 to 1-17 VVC
+
PM
The default control parameters for VVC
+
PM motor control
core are optimized for applications and inertia load in the
range of 50>Jl/Jm>5. Jl is load inertia from the application
and Jm is machine inertia.
For low inertia applications (Jl/Jm<5), it is recommended
that parameter 1-17 Voltage lter time const. is increased
with a factor of 5–10. Sometimes,
parameter 14-08 Damping Gain Factor should also be
reduced to improve performance and stability.
For high-inertia applications (Jl/Jm>50), increase
parameter 1-15 Low Speed Filter Time Const. and
parameter 1-16 High Speed Filter Time Const. to improve
performance and stability.
For high load at low speed (<30% of rated speed), it is
recommended that parameter 1-17 Voltage lter time const.
is increased due to non-linearity in the inverter at low
speed.
1-14 Damping Gain
Range: Function:
120
%*
[0 -
250 %]
The parameter stabilizes the PM motor to ensure
smooth and stable operation. The value of
damping gain controls the dynamic performance
of the PM motor. Low damping gain results in
high dynamic performance and a high value
results in a low dynamic performance. The
dynamic performance is related to the motor data
and load type. If the damping gain is too high or
low, the control becomes unstable.
1-15 Low Speed Filter Time Const.
Range: Function:
Size
related*
[0.01 -
20 s]
High-pass lter damping time constant
determines the response time to load
steps. Obtain quick control through a
short damping time constant. However,
if this value is too short, the control
becomes unstable. This time constant is
used below 10% rated speed.
1-16 High Speed Filter Time Const.
Range: Function:
Size
related*
[0.01 -
20 s]
High-pass lter damping time constant
determines the response time to load
steps. Obtain quick control through a
short damping time constant. However,
if this value is too short, the control
becomes unstable. This time constant is
used above 10% rated speed.
Parameters
VLT
®
HVAC Basic Drive FC 101
32 Danfoss A/S © 04/2018 All rights reserved. MG18B502
33
