Danfoss VLT HVAC Basic Drive FC 101 Programming Guide

8-43 PCD Read Conguration
Dierent parameters can be assigned to PCD 3–10 of the PPOs
(the number of PCDs depends on the PPO type). PCD 3–10 hold
the actual data value of the selected parameters.
Option: Function:
[34] [1694] Ext. Status Word
3.8.4 8-5* Digital/Bus
Parameters for conguring the control word digital/bus
merging.
8-50 Coasting Select
Option: Function:
NOTICE
This parameter is active only when
parameter 8-01 Control Site is set to [0]
Digital and control word.
Select control of the coasting function via the
terminals (digital input) and/or via the bus.
[0] Digital
input
Activates coast via a digital input.
[1] Bus Activates coast via the serial communication
port.
[2] Logic
AND
Activates coast via the eldbus/serial communi-
cation port, and via 1 of the digital inputs.
[3] * Logic OR Activates coast via the serial communication port
or via 1 of the digital inputs.
8-51 Quick Stop Select
Option: Function:
NOTICE
This parameter is active only when
parameter 8-01 Control Site is set to [0]
Digital and control word.
Select control of the quick stop function via the
terminals (digital input) and/or via the bus.
[0] Digital
input
Activates quick stop via a digital input.
[1] Bus Activates quick stop via the serial communi-
cation port.
[2] Logic
AND
Activates quick stop via the serial communi-
cation port and via 1 of the digital inputs.
[3] * Logic OR Activates quick stop via the serial communi-
cation port or via 1 of the digital inputs.
8-52 DC Brake Select
Option: Function:
NOTICE
This parameter is active only when
parameter 8-01 Control Site is set to [0]
Digital and control word.
Select control of the DC brake via the terminals
(digital input).
[0] Digital
input
Activates DC brake via a digital input.
[1] Bus Activates DC brake via the serial communication
port.
[2] Logic
AND
Activates DC brake via the serial communication
port and via 1 of the digital inputs.
[3] Logic OR Activates DC brake via the serial communication
port or via 1 of the digital inputs.
8-53 Start Select
Option: Function:
NOTICE
This parameter is active only when
parameter 8-01 Control Site is set to [0]
Digital and control word.
Select control of the frequency converter start
function via the terminals (digital input).
[0] Digital
input
Activates a start command via a digital input.
[1] Bus Activates a start command via the serial
communication port or eldbus options.
[2] Logic
AND
Activates a start command via the serial
communication port and via 1 of the digital
inputs.
[3] * Logic
OR
Activates a start command via the serial
communication port or via 1 of the digital inputs.
8-54 Reversing Select
Option: Function:
NOTICE
This parameter is active only when
parameter 8-01 Control Site is set to [0]
Digital and control word.
Select control of the frequency converter reverse
function via the terminals (digital input) and/or
via the serial communication port.
[0] * Digital
input
Activates a reverse command via a digital input.
[1] Bus Activates a reverse command via the serial
communication port.
Parameters
VLT
®
HVAC Basic Drive FC 101
64 Danfoss A/S © 04/2018 All rights reserved. MG18B502
